VDI Hydraulic Driven Holder

  • RADIAL AXIAL MILLING AND DRILLING HEAD

  • AXIAL MILLING AND DRILLING HEAD

  • RADIAL MILLING AND DRILLING HEAD

Product Overview

The Hydraulic Chuck is a high-precision tool holder widely recognized for its superior clamping accuracy, stability, and vibration-damping properties. Its primary function is to secure cutting tools with high concentricity, ensuring minimal runout and maintaining exceptional surface finish in machining. Hydraulic chucks use a built-in hydraulic mechanism to generate uniform clamping force around the tool shank, which reduces stress points compared to traditional clamping methods. They are used in milling, drilling, reaming, and finishing applications where precision and repeatability are essential. By eliminating micro-vibrations and ensuring stable clamping, hydraulic chucks enable manufacturers to achieve better dimensional accuracy, extended tool life, and higher productivity across both low-volume precision parts and large-scale production runs.

Product Features

Hydraulic chucks stand out because of their precision engineering and advanced clamping technology:

Ultra-High Accuracy: Runout accuracy typically ≤0.003 mm, delivering superior machining precision.

Excellent Vibration Damping: The hydraulic mechanism absorbs cutting vibrations, improving surface quality and protecting both the tool and spindle.

Uniform Clamping Force: Provides 360° tool shank support, reducing stress concentrations and ensuring stable performance at high speeds.

Easy Tool Changes: With a simple hex key adjustment, operators can quickly clamp or release tools without the need for additional equipment.

Wide Compatibility: Available in HSK, BT, CAT, PSC, and other interface standards, making them adaptable to different CNC machine types.

Versatile Application: Suitable for high-speed finishing, reaming, drilling, and light milling where accuracy is critical.

These features make hydraulic chucks an ideal choice for manufacturers seeking a balance of precision, efficiency, and tool longevity.

Product Specifications

Hydraulic chucks are produced in a wide range of specifications to accommodate various machining needs:

Clamping Range: Typically 3 mm – 32 mm depending on the model.

Runout Tolerance: ≤0.003 mm, supporting high-precision finishing operations.

Shank Interface: Available in HSK (A, E, F types), BT, CAT, PSC, and other international standards.

Length Options: Standard, medium, and extended lengths for different machining depths.

Balancing Grade: G2.5 at 25,000 RPM, ensuring excellent performance in high-speed spindles.

Clamping Method: Hydraulic chamber activated by a simple hex key for reliable and repeatable clamping.

With these specifications, hydraulic chucks can be applied in both high-speed finishing and precise drilling operations, delivering consistent results across different machining conditions.

Product Instructions and Best Practices

For optimal performance and longer service life, hydraulic chucks should be used and maintained according to best practices:

Preparation: Clean both the tool shank and chuck bore before installation to prevent dirt or chips from affecting clamping accuracy.

Clamping: Insert the cutting tool to the required depth and tighten using the supplied hex key until resistance is felt, ensuring secure hydraulic pressure.

Operation: Match cutting parameters with the clamping range and spindle speed. Avoid exceeding maximum RPM specifications.

Tool Changes: Replace tools quickly by releasing hydraulic pressure with the hex key — no complex adjustments needed.

Maintenance: Regularly inspect the hydraulic mechanism and seals. Store chucks in a clean and dry environment to prevent hydraulic fluid leakage or internal corrosion.

By following these instructions, hydraulic chucks guarantee stable tool holding, long-term precision, and reduced downtime in machining operations.

Applicable Industries

Hydraulic chucks are widely adopted in industries where accuracy and repeatability are critical:

Aerospace: For precision machining of turbine components, engine housings, and structural parts requiring tight tolerances.

Automotive: For high-volume production of engine blocks, transmission housings, and fuel system components with strict quality requirements.

Medical Devices: For implants, surgical tools, and miniature precision parts where flawless surface finish is essential.

Electronics and Precision Engineering: For micro-parts and fine machining operations requiring high accuracy.

Mold and Die Manufacturing: For boring and finishing mold cavities with excellent surface quality and dimensional stability.

This broad range of applications demonstrates how hydraulic chucks help industries achieve higher product quality, lower scrap rates, and more efficient production cycles.

Product Customer Groups

The main customer groups for hydraulic chucks include:

CNC machining workshops specializing in high-precision parts and prototypes.

Automotive OEMs and suppliers requiring reliable tool holders for high-volume production lines.

Aerospace manufacturers demanding tool stability and accuracy in complex machining processes.

Medical device producers working with small, intricate, and safety-critical components.

Mold and die makers who require precise finishing to ensure mold accuracy and product quality.

General manufacturing companies looking to improve machining accuracy and reduce tool replacement costs.

By catering to these customer groups, hydraulic chucks enable businesses to achieve higher machining standards, streamline operations, and reduce overall production costs.

The Hydraulic Chuck is a proven solution for manufacturers who value precision, stability, and efficiency in CNC machining. With its hydraulic clamping system, it provides superior runout accuracy, excellent vibration damping, and quick-change capability, making it ideal for high-speed finishing and precision drilling. From aerospace to automotive, medical to mold manufacturing, hydraulic chucks are trusted across industries where machining quality cannot be compromised. By investing in high-quality hydraulic chucks, manufacturers can achieve improved productivity, reduced tool wear, and consistently excellent machining results.
